Orthopedic Insole Manufacturing Grinding Unit

A Podiatry Orthotics polisher that is both functional and ergonomic, featuring a fundamental design. The Operator is safeguarded from dust and debris by the expansive bent glass. The Operator can access the manipulation area from both the front and the sides due to the large surrounding comb, which extends on both sides.The Operator can effortlessly transition from one polishing roll to another with the assistance of the Labor Cab. The LED light sources guarantee a complete and bright illumination of the work area, free of any glare.A suction motor may also be connected to a labor cab.

– epoxy powder is used to paint the steel structure

– laminated glass with a lifting arm that is bent.

– 700 mm leg supports

– velocity (2,800 revolutions per minute)

– 500 watts of power

– external service switch for the polisher and the lamp

– nylon filaments that are antistatic

– abrasive wheels with a diameter of 90mm and a width of 70mm (width 100mm is also available)

– arrangement for suction connection Two 32mm pieces

– Three LED light sources

– shelf with adjustable height that is affixed to the leg support.input:
output:The Operator is able to access the working area from both the front and the sides with ease, as the large surrounding comb extends on both sides. INCLUDED IN THE STANDARD VERSION.Laminated glass that has been bent and is equipped with a lifting arm. INCLUDED IN THE STANDARD VERSION.input:
output:230 V/50Hz power supply

Employment Cabin absorption: 510 watts

Speed of tollsSingle-speed motor: 2800 revolutions per minute

Motor with two speeds: 1400-2800 revolutions per minute

Noise level: greater than 50 decibels

Weight: 80 kilograms

Overall dimensions: 936 x 544 h 1285

INCLUDED IN THE STANDARD VERSION.input:
output:The working area is illuminated in a bright and complete manner without any glare from LED light sources. INCLUDED IN THE STANDARD VERSION.
