Optical Ophthalmic Biometer

One-button measurement technology that is fully automatic

The automatic eye-location, automatic focusing, and automatic measurement can be completed by clicking the "Start measuring" button on the interface.input:
output:Rapid measurementinput:
output:Three to four groups of data are collected in a single second, and both eyes are measured in a mere 25 seconds.input:
output:By pressing a single button, eight eye parameters can be measured.input:
output:Including the following: axial length, corneal curvature, axial view angle, cornea thickness, anterior chamber depth, lens thickness, white to white distance, and pupil size.input:
output:
Eye Care Cloudinput:
output:Personal ophthalmic data files can be established to assist in the prevention and management of myopia in children and adolescents, and the measured data can be uploaded to the eye care cloud.input:
output:Simple to operate and train

Operators can rapidly commence operations with mere minutes of instruction.input:
output:Visual acuity screening for the prevention and management of myopia in children and adolescents

Simple operation, rapid measurement, and appropriate for large-scale screening projects, such as those conducted in schools.

Establish personal visual health records to facilitate the timely and effective identification of visual changes, which are appropriate for the prevention and management of myopia in children and adolescents.

A variety of measurement modes are available to accommodate the needs of various scenarios.

The diagnosis of refractive myopia and axial myopia is facilitated by the measurement of corneal curvature and axial length.Specificationinput:
output:Axial resolution of 0.01mm, ±25μm, axial length of 12–34mm

Corneal curvature: 4.7–11.2mm, resolution 0.01mm, ±10μm

Resolution: 1°, ±9°, axial view angle: 0°~180°

Corneal depth: 300–800 μm, resolution 1 μm, ±2 μm

Anterior chamber depth: 1.5–6.0 mm, resolution 0.01 mm, ±20 μm

Lens thickness: 0.5–7.0mm, resolution 0.01mm, ±50μm
