Ophthalmic Surgery Microscope

The Coaxia LED light source is employed by the ROMS 100.The lighting system is equipped with a Retina Protection Device, an independent red reflex intensifier with a -2° angle, and an infrared filter. The X/Y system is automatically programmable, and the X/Y moving range is 50mm.The instrument employs a gas spring counter balance at each fixed point.The technical data is stable and reliable, while the performance is easy and flexible.Eyepieces: 12.5x-7D to +7D diopter adjustment rangeObjective: 200mm focal lengthWorking Distance: 190mmZOOM 6:1 Motorized Magnification of Main Optics SystemMagnifications: Main Optics: 4.1X to 24.6X; Assistant Optics: 5.4X, 8X, and 12.2XMain Optics Field Diameter: 8mm to 50mm Assistant Optics: 34.6mm, 23mm, 14.63mmPD For Main Binocular - 51mm to 75mmPD For Assistant Binocular - 55mm to 75mmMain Binocular Tilt Range: 0 to 180°Focusing - 50mm, motorized with automatic resetFocusing Speed: ≤2mm/sFilters - Main Illuminator: Retina Protection Filter, Red-free, GG435 Blue-blocking; Red Reflex Illuminator: 20% Light Attenuation Extendable For Two OperatorsFloor Stand Data

extendable for three operatorsFoot wheels - four 100mm diameter wheelsWeight: approximately 185 kg, full microscope system.Extension - Range 1380mm (Maximum)Gas spring balancingXY Unit - 50mm*50mm, Motorized with Automatic ResetXY Moving Speed - ≤2mm/sXY Moving Speed - ≤2mm/sTilt Driver - Manual, +15°/-50°Turning Range: 360° for the horizontal arm, ±135° for the balance arm, and ±135° for the XY unit.
