Ophthalmic Laser

On modular architecture, multicolor

A variety of scan patternsAuto-forwardingLPM (Low Power Mode)Features that are both practical and user-friendly

Delivery unit alternativesinput:
output:Comprehensive Detailsinput:
output:On modular architecture, multicolorinput:
output:The MC-500 Vixi / MC-500 enables the selection of one, two, or three wavelengths from green, yellow, and red.input:
output:A variety of scan patternsinput:
output:The MC-500 Vixi is equipped with 22 preprogrammed scan patterns that facilitate the treatment of a variety of retinal pathologies.input:
output:*One The number of spots in horizontal and vertical directions is denoted by No. v No. for equal space patterns.2*
The arcade grid pattern is employed to treat the periphery of the macula in one-sixth units. The spot sizes are 100 to 200 μm, and the inner diameter remains constant.input:
output:Autoforward*



The MC-500 Vixi enables the automated positioning of the scan pattern to the next region undergoing photocoagulation after the photocoagulation process is finished in one region. This feature enables the surgeon to concentrate on the adjustment of focus.input:
output:The auto forward function of the repeat mode allows for the photocoagulation of consecutive regions along a predetermined path without the need to repeatedly press the foot switch.*

The auto forward function is accessible for the square (2x2, 3x3, 4x4) and the equal space (2v2, 3v3, 4v4) patterns.input:
output:The frequency of forwarding is contingent upon the scan pattern, spot size, and spacing.input:
output:LPM (Low Power Mode) is a technique for minimally invasive photocoagulation.input:
output:LPM (Low Power Mode) is a laser treatment that administers diminished power to the retina. The standard (yellow) laser treatment power is reduced by a specific ratio in LPM. The yellow laser must be installed on the MC-500 Vixi in order to utilize the optional LPM.
