Product fit review
Compare the available product information with your application and purchasing requirements.
Medical equipment Select an image to inspect
Available for inquiry Specification-led inquiry
Medical equipment sourcing
Operating Room Video Recording System
Reference: 787522Healthcare It, Telemedicine
| Other Characteristics | Usb |
| Applications | Operating Room |
Associated tags
Documentation request
Ask which specifications, manuals, or commercial documents are available for review.
Supplier coordination
Discuss quantity, destination, packaging, and timing before confirming suitability.
Product information
Product summary
Surgical Video Recording SystemSpecifications - Power: 100-240 V AC, 50/60 Hz - Input Current: 1.5 A - Inputs: HDMI Type A (x2) – 1024 x 768, 1280 x 1024, 1920 x 1080
HD-SDI (x2) – 720p/60, 1080p/30, 1080i/60, 1080p/60
Audio Line In (x2) - Outputs: - HDMI Type A (x1) - VGA DE-15 (x1) - Audio Line Out (x1) - Storage: Internal 1TB hard drive
External USB storage is optional. - MPEG-4 AVC/H.264 compression
- Video File Formats: MPEG4, AVI, MOV, and JPEG
- Additional interfaces: - USB Type A (x3) – USB 2.0 - RJ-45 (x1) – Ethernet 100Base-T - Foot pedal (x2) – optional - Dimensions of the unit: 350 mm in width, 235 mm in height, and 40 mm in depth. - Compatible devices include the Da Vinci.- Microscope
- Endoscope
- Navigation
HD-SDI (x2) – 720p/60, 1080p/30, 1080i/60, 1080p/60
Audio Line In (x2) - Outputs: - HDMI Type A (x1) - VGA DE-15 (x1) - Audio Line Out (x1) - Storage: Internal 1TB hard drive
External USB storage is optional. - MPEG-4 AVC/H.264 compression
- Video File Formats: MPEG4, AVI, MOV, and JPEG
- Additional interfaces: - USB Type A (x3) – USB 2.0 - RJ-45 (x1) – Ethernet 100Base-T - Foot pedal (x2) – optional - Dimensions of the unit: 350 mm in width, 235 mm in height, and 40 mm in depth. - Compatible devices include the Da Vinci.- Microscope
- Endoscope
- Navigation
