Operating Room Laminar Flow Module

The NICFA® AirFlow has been EC certified and patented in accordance with a variety of international regulations. input:
output:The NICFA® AirFlow is engineered to meet the requirements of all unidirectional air flow diffusers for operating theaters, with the goal of achieving optimal performance in ISO5 classified operating theaters.input:
output:
The low ceiling height is user-friendly, even in the presence of a false ceiling. The primary characteristics of the NICFA® AirFlow The AISI316 stainless steel plenum, which is situated in the nonare: a small space between the slab sterile part, is capable of feeding all four sides as required, owing to the unique shape of the recirculation unit. The mixing chamber contains the compression grid of the absolute filters, which is constructed from AISI316 stainless steel.
PATENTED AND EC CERTIFIEDinput:
output:The AISI316 stainless steel containment grid is a horizontal structure that houses the H14 absolute filters, which can be adjusted to a height of 68/78/88mm based on the design requirements. This arrangement reduces manual handling and eliminates the need for diffuser tools. The filters cover 92% of the grid and are evenly distributed across its entire surface. The double grid system with a double seal guarantees the absolute filters’ integrity, thereby preventing any potential leakage. input:
output:
A synchronized automatic system ensures a uniform and reliable double seal on the compression grid by moving the two containment grids independently via a special command from the NICFA® Controller. The mixing process is cleaned and sanitized at predetermined intervals as a result of the innovative tilting movement system.
