On-Platform Ultrasound System
Reference: 1002898
Cardiology
| Probe Type | Convex-Array, Linear-Array, Microconvex-Array |
| Ergonomics | On-Platform |
| Application | For Multipurpose Ultrasound Imaging, For Gynecological And Obstetric Ultrasound Imaging, For Abdominal And Pelvic Ultrasound Imaging, For Urology Ultrasound Imaging, For Cardiovascular Ultrasound Imaging, For Endovaginal Ultrasound Imaging, For Transrectal Ultrasound Imaging |
| Imaging Modes | B/W |
Documentation request
Ask which specifications, manuals, or commercial documents are available for review.
Supplier coordination
Discuss quantity, destination, packaging, and timing before confirming suitability.
Product information
Product summary
Platform - PC Control Platform based on the WINDOWS system Scanning Model - Electronic Linear Array, Electronic Convex Array Image Storage - BMP, JPG, DCM, and TIF are available; built-in hard disk≥160G Display Depth - 250mmScanning Angle - ≥152ºImage Processing - Gamma, tissue harmonic, scanning line density, and edge enhancement Histogram, Correction
image enhancement - ≥7 types
pseudo-color - ≥ 10 types
Focus Adjustment - The focus number must be at least 4, and the focus span and position can be adjusted.
Patient Records
Management System - The following functions are available: Add, Search, Revise, and Report.External ports include a video port, RS-232 port, USB port, DICOM3.0 port, PS/2 port, and XGA port.• Utilizing a variety of technologies, including digital scan converter (DSC), digital beam forming (DBF), real-time dynamic aperture (RDA), dynamic receive apodization (DRA), dynamic receive focusing (DRF), and dynamic frequency scan (DFS).• Image optimization and enhancement, smoothing, frame correlation processing, pseudo-color, Gamma Correction, and Real-time Zoom/Zoom to area
• The report is generated automatically in accordance with the image collection, diagnostic description, and measurement. projects.• A comprehensive and diverse image text medical records management function;
A typical and upgradable medical records import/export function; these two functions are capable of meeting the requirements of extended clinic applications.
image enhancement - ≥7 types
pseudo-color - ≥ 10 types
Focus Adjustment - The focus number must be at least 4, and the focus span and position can be adjusted.
Patient Records
Management System - The following functions are available: Add, Search, Revise, and Report.External ports include a video port, RS-232 port, USB port, DICOM3.0 port, PS/2 port, and XGA port.• Utilizing a variety of technologies, including digital scan converter (DSC), digital beam forming (DBF), real-time dynamic aperture (RDA), dynamic receive apodization (DRA), dynamic receive focusing (DRF), and dynamic frequency scan (DFS).• Image optimization and enhancement, smoothing, frame correlation processing, pseudo-color, Gamma Correction, and Real-time Zoom/Zoom to area
• The report is generated automatically in accordance with the image collection, diagnostic description, and measurement. projects.• A comprehensive and diverse image text medical records management function;
A typical and upgradable medical records import/export function; these two functions are capable of meeting the requirements of extended clinic applications.
