Nucleic Acid Extraction Laboratory Workstation

The Stream SP96 is a high-throughput nucleic acid extraction instrument that utilizes magnetic bead technology. This DNA/RNA extraction machine has the capability to automatically extract nucleic acids from 1 to 96 samples, thereby significantly enhancing working efficiency and reducing the need for manual operation. As a molecular diagnostic equipment, the Stream SP96 automated DNA/RNA extraction machine is capable of accurately loading and placing reagents, thanks to its precise liquid handling technology, anti-contamination design, and exceptional magnetic extraction function.input:
output:Features of the Stream SP96 Automatic Nucleic Acid Extraction System


◆ High throughput: In a mere 18 minutes, 96 samples can be extracted.

flexible: In a single run, nine distinct types of PCR reactions may be established.

◆ The extracted DNA/RNA can be aliquoted into a 3*96 PCR mix.

◆ Ultra-precision liquid handling technology.

◆ Anti-contamination: UV light, 100% exhaust airflow circulation, and HEPA filter system.Stream SP96 Automatic Nucleic Acid Extraction System SpecificationSample throughput: 96 samples

Reaction volume: 20 μL to 1000 μL (Dual sample extraction is available)

Controlled temperature range for extractionFrom room temperature to 99℃

Context of operationHumidity: ≤70%, Temperature: 10℃~30℃

The extracting module's temperature control tolerance is ±1℃.Performance of pipetting 20µL-100µL Accuracy: 1% Repeatability is less than 0.6%.

100-1000 µL Precision: 0.8% Repeatability is less than or equal to 0.5 percent.

Anti-pollution design UV light, 100% exhaust airflow circulation, and HEPA filter systemSpecs (mm): 1300 x 745 x 1707

250 kilograms of net weight
