Non-Mydriatic Retinal Camera

The Gaush Raymond TNF506 Fundus camera is a device that is designed to capture images of the retina of the eye. It is capable of producing three distinct image types: color, non-mydriatic color, and red-free.input:
output:Features of the product:input:
output:●Sophisticated fundus imaging system● Installation is effortlessinput:
output:●Images of exceptional qualityinput:
output:● An option for small pupils is available. input:
output:Technical parameters:➣Image type: Color, non-mydriatic, red-freeinput:
output:
➣ Field of View: 45°input:
output:➣Minimum pupil diameter: Non-Mydriatic: 3.5 mm (under small pupil mode)input:
output:➣ Diopter compensation: ±15Dinput:
output:➣ Working distance: 42 mminput:
output:➣Fixation target: Internal LED green light and external LED lightinput:
output:➣ Movement of the base: ➣Base movement: Forward and backward: 60mm➣Left and right: 110mm➣Up and down: 30 mminput:
output:➣Panning range: Left: 30°, Right: 30°input:
output:tilting range: Upward: 15° Reverse: 10°input:
output:Optional:



SLR imaging system, external Canon camera with 24MPinput:
output:Gaush Raymond TNF507 The fundus camera is a device that is used to capture an image of the retina of the eye. It has four image types: color, non-mydriatic color, FFA, and red-free.input:
output:Features of the product:●Fundus camera with Non-mydriatic+FFAinput:
output:●Ideal for inspecting details through magnification● Installation is effortless.● Data port available for transmissionTechnical parameters:➣Image type: Color, non-mydriatic color, FFA, Red-freeinput:
output:➣ Field of View: 50°input:
output:➣ Working distance: 42mminput:
output:➣ LCD retinal observation modeinput:
output:➣The minimum pupil diameter for non-mydriatic eyes is 3.5 mm when operating in the "small pupil mode."➣LED lights are the target for fixes.input:
output:➣ Diopter compensation: ±15Dinput:
output:➣Auxiliary focus mode: Two light spots for focusinput:
output:➣Focus type: Auto focus/Splitting line focusinput:
output:➣Base movement: 80mm forward and backward Left and right: 100mminput:
output:➣Tilting range: Up: 15°, Down: 10°input:
output:➣ Range of view: Left: 30°, right: 30°
