Multipurpose Radiography X-Ray Generator
Reference: 932449Radiology
| Options | With Control Panel |
| Type Of Imagery | For Multipurpose Radiography |
| Ergonomic Design | Floor-Mounted |
Associated tags
Documentation request
Ask which specifications, manuals, or commercial documents are available for review.
Supplier coordination
Discuss quantity, destination, packaging, and timing before confirming suitability.
Product information
Product summary
The Genesis DT's cutting-edge and innovative technology is designed to meet the rapidly evolving needs of digital x-ray technology, including tomosynthesis and flat panels.input:
output:Converter frequency: 120 kHz
Tube voltage: 40–125 kV (optional up to 150 kV)
Tube current range: 0.5 …. 650mA (750mA, 800mA)mAs-range: 0.4600mAs
Exposure time: 0.001... 6 seconds
Accommodates both analog and digital AEC-measuring chambers
Anatomical programs that are both freely programmable and controllable (through procedure-codes)
There are three exposure techniques: one, two, and three points.
Fluoroscopy, both continuous and pulsed
Integrated dose area product meter (DAP)Integrated high-speed starter (65kW as an option, 80kW as standard)User-friendly touchscreen operationAlternatively, operation may be accomplished through an external personal computer.Capable of being integrated into the host systemInstallation and maintenance are effortless and supported by software.
output:Converter frequency: 120 kHz
Tube voltage: 40–125 kV (optional up to 150 kV)
Tube current range: 0.5 …. 650mA (750mA, 800mA)mAs-range: 0.4600mAs
Exposure time: 0.001... 6 seconds
Accommodates both analog and digital AEC-measuring chambers
Anatomical programs that are both freely programmable and controllable (through procedure-codes)
There are three exposure techniques: one, two, and three points.
Fluoroscopy, both continuous and pulsed
Integrated dose area product meter (DAP)Integrated high-speed starter (65kW as an option, 80kW as standard)User-friendly touchscreen operationAlternatively, operation may be accomplished through an external personal computer.Capable of being integrated into the host systemInstallation and maintenance are effortless and supported by software.
