Multipurpose Radiography X-Ray Generator

The ANTHEM is capable of operating in three user-friendly modes: APR (Anatomically Programmed Radiography), 2-point or 3-point technique set-up, and allows for customization of operation to accommodate the specific requirements of the practice and the technologist's preferences. Select the region of interest, select the desired examination, and then select patient size to display the pre-programmed technique. The programming process of the ANTHEM enables authorized personnel to rapidly modify the programmed mA, kV, and time. The software will automatically select the highest mA and shortest time to reduce motion and deliver high-quality images when the 2-point operation of setting mAs and kV is used. The traditional 3-point selection of kV, mA, and time is designed to meet the preferences of certain technologists and the requirements of specialized perspectives.Technical SpecificationsMAXIMUM MA 650

KVP RANGE: 40-125 kVp

TWO-POINT OPERATION mAs range: 1.0-600THREE-POINT OPERATION 15 mA stations:25S, 50S, 75S, 100S, 100L, 150L, 200L, 250L, 300L, 350L, 400L, 450L, 500L, 550L, 600L, and 650L.

TIME STATIONS: 75

CALIBRATION TIME: 10-15 minutes

POWER SUPPLY 208/240 VAC, single phase208/240/380/480 VAC 3-phase AVAILABLE CONFIGURATIONS -400 mA, 30 kW, 1P

-500 mA, 32 kW, 3P

-500 mA, 40 kW, 1P

-600 mA, 40 kW, 3P

-650 mA, 50 kW, 3PCHOICES

-Console wall mount-Hand switch for exposure-Automatic exposure control (AEC)-In-table version (Only available on RT100 radiographic tables)
