Multiparametric Test Strip Reader

The Neotest Test Strip Reader is a novel meter that is designed to read immunochromatographic rapid test strips. This optical measurement system is highly sensitive, rapid, and effective, performing both qualitative and quantitative analyses of lateral flow assays, which are immunological rapid tests used for point-of-care testing. It is capable of simultaneously detecting up to five lines on a test strip or test cassette. The built-in printer generates the final results.input:
output:Note: While all Neotest strips are intended for use without a reader, there are certain circumstances in which a reader may be beneficial.input:
output:The following are the features:6.2-inch touch screen that is both user-friendly and efficientinput:
output:
High-repeatability, high-sensitivity measurementinput:
output:
Supports the development of a diverse array of reagents.More than 10,000 measurement records can be stored in the large built-in memory, which can be accessed at any time.input:
output:Intensity calculation and automatic line position detectionDetailed technical informationinput:
output:Dimensions of the test strip: width: 3–5 mm, length: <75 mm; suitable for all Neotest strip tests.The dimensions of the test cassette are 70 x 20 x 5mm (L x W x H).input:
output:Wavelength: 525±30 nminput:
output:Colorimetric detection: carbon, colored latex beads, colloidal gold, and so forth.Number of test lines per strip: up to five test/control lines per strip.Time required for measurement: less than 15 seconds for each test strip.Stability is defined as a relative drift value of no more than 3% within a two-hour period.Microthermographic printerinput:
output:Internal SD card (2 GB)input:
output:Two USB ports (for the connection of a keyboard and mouse)input:
output:humidity: ≤80%, operating temperature: 15–40℃input:
output:Dimensions (D x W x H): 320 mm x 196 mm x 156 mmInput power: AC 100-240V 50/60Hz, DC 12V 4AWeight: 3.4 kilograms
