Multiparametric Simulator
Reference: 430355Monitoring
| Application | Emergency Care, For Intensive Care |
| Other Characteristics | With Touchscreen |
| Form | Monitor |
| Procedure | Multiparametric, Vital Sign |
| Simulated Pathology / Condition | Arrhythmia |
| Configuration | Portable |
Associated tags
Documentation request
Ask which specifications, manuals, or commercial documents are available for review.
Supplier coordination
Discuss quantity, destination, packaging, and timing before confirming suitability.
Product information
Product summary
The MS400 Multi-parameter Simulator is a lightweight and compact device. It is capable of accurately simulating 12-lead ECG, Respiration, Temperature, 2-channel IBP, or 4-channel IBP. Additionally, it may be evaluated in the context of the monitor's utilization.Functionsinput:
output:
Generate four-channel IBP data.
Adjustable respiration rate, baseline impedance, and three types of apnea data are used to simulate the respiration signal.
Four types of temperature data are simulated.
Adjustable frequency simulations of square wave, triangle wave, pulse wave, and sine wave are implemented.
Simulate the standard ECG calibration, as well as the ECG signals of both adults and children.
The simulator can display ECG waveform data stored in a TF card that complies with the standards of ANSI/AAMI EC13-2002, AHA, MIT ECG database, other ECG databases, and user-defined waveform data by exporting it to the equipment to be tested.
The 3.5 TFT touch screen is user-friendly and can be used to display each waveform by sliding it.
Power source: linear adapter or rechargeable lithium battery, which mitigates interference.
Optional modes of operation include touch screen and keys.
output:
Generate four-channel IBP data.
Adjustable respiration rate, baseline impedance, and three types of apnea data are used to simulate the respiration signal.
Four types of temperature data are simulated.
Adjustable frequency simulations of square wave, triangle wave, pulse wave, and sine wave are implemented.
Simulate the standard ECG calibration, as well as the ECG signals of both adults and children.
The simulator can display ECG waveform data stored in a TF card that complies with the standards of ANSI/AAMI EC13-2002, AHA, MIT ECG database, other ECG databases, and user-defined waveform data by exporting it to the equipment to be tested.
The 3.5 TFT touch screen is user-friendly and can be used to display each waveform by sliding it.
Power source: linear adapter or rechargeable lithium battery, which mitigates interference.
Optional modes of operation include touch screen and keys.
