Mobile Support Arm

The OASYS Swing is a suspension system that is adaptable and can accommodate loads of up to 7 kg (15 lbs).

The units are customized to meet your specific needs for the storage and operation of medical devices, such as cameras and examination lights.input:
output:The system facilitates the effortless movement and mobility of the adapted equipment on the ceiling, wall, or floor stand models.input:
output:OASYS is capable of satisfying your customized design requirements, including the selection of colors, customized lengths, and loads. We are dedicated to delivering exceptional customer service, ensuring timely delivery, and providing superior quality.input:
output:OASYS Swing arms are ideal for customers who have a diverse selection of light options, as they provide the broadest load range available. Our extensive selection of color and sizing customization options enables customers to design the product that is most suitable for their needs.input:
output:Spring Arm Length: 550 mm/720 mm (21″/28.5″) (Straight Arm) 720 mm (28.5″) (21″/28.5″) (Bent Arm)

Length of Extension Arm: 800 mm/1270 mm (31.5″/50″)

Maximum Load: 42 Nm (Straight Arm) 42 Nm (Bent Arm)

Load Ranges: 3-15 Nm, 14-42 Nm (Straight Arm) 3-15 Nm, 14-42 Nm (Bent Arm)Ceiling Drop Tube Length: 150-800 mm (6″-31.5″) (Straight Arm) and 150-800 mm (6″-31.5″) (Bent Arm)

The maximum cable allowance is 62mm2 (2.44in2).

The maximum single cable diameter is 8.5mm (0.33 inches).

Options include an adjustable load, non-stop rotation, and ease of maintenance.

Safety Factors: Yield strength is calculated at four times the payload in accordance with IEC 60601.

Approvals: CE, URC, UR

Electrical: 12 A, 100-240 V

Classification: IEC 60601-1, UL 60601-1, CAN/CSA-C22.2 No. 601.1-M90

Color: RAL 9010, RAL 7035, and RAL 9002.
