Microscope Camera

Authentic high-definition imaging for industrial and scientific applications. Capture still images with a resolution of 6MP.

Utilize the 11.6″ HD monitor that is included to view and capture images in the absence of a personal computer.

Integrated mouse control software for HDMI viewing and recording without the need for a computer.

Live image output to an HD monitor and a PC/Mac can be achieved simultaneously through USB2.0 (PC/Mac not included).input:
output:Perform measurements on live HD images.

Fluorescence imaging with a high signal-to-noise ratio, exposure times ranging from 1 millisecond to 10 seconds, and 20 gain levels.input:
output:By mounting the monitor directly to the body of the Excelis HD camera, it is easy to access and does not occupy valuable bench space.input:
output:The Excelis HD’s capabilities are enhanced by the CaptaVision Imaging Software (included), which offers sophisticated image processing and measurement capabilities (PC required; not included).

The standard C-mount is easily compatible with the majority of microscopes; it is advisable to use a 0.35x camera adapter.One-year warranty.input:
output:The following items are included in the package: The Excelis HD Camera, 11.6″ HD display, display bracket and screws, HDMI Cable, HDMI adapter, USB 2.0 Cable, Y power splitter cable, 12V Power Adapter, 8GB SD Card, USB Mouse, and CaptaVision PC Imaging Software.Camera Specificationssensor – 1/2.8″ SONY IMX236 color CMOS, 2.8µm pixels

Frame Rate – HDMI: 60fps / USB2.0: 30fps

Image Capture – Hi-Speed SD Card (8GB); capable of accepting Class 10 SD cards with a maximum capacity of 32GB.Video Capture – HDMI: 1080p, 30fps to SD Card / USB2.0: 1080p, 30fps to PC

Exposure Time – 0.001 sec – 10.0 secAutomatic White Balance

Additional Settings: Gamma, Gain, Saturation, and Contraction

Cloud 1.0 (with live image measurement) – Built-in Software (stand-alone operation)PC Imaging Software – CaptaVision Imaging Software (separate software for Mac OS and PC/Windows)
