Medical equipment sourcing

Medical Valve

Reference: 855723Components For The Medical Industry
ApplicationsMedical
TechnologyProportional
request_quote Request product information Back to catalog

Associated tags

Proportional
manage_search

Product fit review

Compare the available product information with your application and purchasing requirements.

description

Documentation request

Ask which specifications, manuals, or commercial documents are available for review.

support_agent

Supplier coordination

Discuss quantity, destination, packaging, and timing before confirming suitability.

support_agent Request info description

Product information

Product summary

fifty-fifty The 68P proportional valve is characterized by a 15 mm width and offers two distinct electrical connection options. The flow can be continuously adjusted due to the consistent valve opening. The valve's distinctive characteristic curve is reflected in the proportional relationship between control input and flow, which can be regulated with the use of suitable sensors and electronics to achieve high precision.input:
output:2/2-way NC function

Pressure range: 0 to 8 bar

Nominal orifice: 1.3 mm
Kv-value: 0.7 liters per minuteDimensions: 15 millimeters
Actuation type: electrically actuatedDuty cycle: 100% ED

Plug pins/pins are the type of electric connection.

Medium: Filtered (5 µm), lubricated, and non-lubricated air

Nominal power: 4.2 watts

Voltage nominal: 24 volts DC

Pneumatic connection type: Flange

Returning mechanism - SpringProtection class: IP65Ambient temperature ranges from -10°C to +50°C.Valve type: Poppet valveBase: PBT, seal: NBR

Actuation is directly regulated.
