Medical Valve

– 3/2 NC Compact design

– Manifold mountingThe cycle rate exceeds 100 million, indicating a long lifespan.

– Low power consumption– Certification: IECEx, ATEXinput:
output:This valve was specifically engineered to satisfy the rigorous standards of the ATEX industry, guaranteeing the highest levels of safety and performance in explosive environments.input:
output:Medium:Air, oxygen, and neutral gases (100% to 95% humidity, non-condensing), 40 μm filteredinput:
output:Operation:Normally closed, direct-acting three-way valvesinput:
output:Flow:12 liters per minute at a pressure of 7 bar (101 psi) and a temperature of +20°C (+68°F)input:
output:kV factor:0,12 (Cv: 0.008)input:
output:Manifold mounting:input:
output:Orifice:0.5 millimetersResponse time: 25 milliseconds Response time is measured in accordance with ISO 12238input:
output:Life expectancy:20... 100 million cycles(excluding Hit & Hold valves)Mass:30 g (0.07 lbs)Median/ambient temperature:-10°C to +50°C (+14°F to +122°F)

In order to prevent the formation of ice at temperatures below +2°C (+35°F), the air supply must be sufficiently dry.input:
output:Components:Body: PPS

Seat seals: FPM, NBRinput:
output:Internal components are composed of stainless steel.PA 6/6
