Medical Thermosealer

Introduction:The Blood Bag Tube Sealer is a lightweight, compact tube sealer that employs high-frequency sealing technology to prevent hemolysis or blood leakage when sealing blood bags, infusion bags, and urine bags. It is appropriate for blood bags with a sealing time of 2 seconds and a diameter of 2 to 6mm. Constructed with a single chip and an automatic sealing voltage. input:
output:Characteristics:1) Employed in blood-collecting vehicles with suction feet to prevent movement.

2) Single-chip design with automated voltage adjustment for sealing

3) The sealing time is approximately two seconds.

4) Sealer protects the quality of essential components by preventing blood hemolysis and guaranteeing high quality.input:
output:
Applications:Blood bag tube sealers are employed in urine bags, infusion bags, and blood bags through a high-frequency sealing system. Additionally, it is employed in the biological industry, hospitals, and blood banks.input:
output:Details:Model Number: SW-RHJ

Sealing Time: Approximately two seconds

Type of Sealing: Automatic

Tube diameter: φ2-6mm
External dimension:290mm x 160mm x 135mm (L x W x H)Packaging dimensions: 380 x 230 x 240 mm.Net weight: 6 kilogramsGross weight: 7 kilogramsOperating frequency: ≤ 40.68 MHzRadio frequency (RF) power sealing: 30 watts or more

Energy consumption:Working power is limited to 250 watts, while standby power is limited to 5 watts.

AC 185V-264V, 47-63Hz power supply

Electronic Tube Lifespan: 8 hours of continuous use per dayWork conditions that are normal:

1. Ambient temperature: 0℃ to 40℃2. Relative humidity: 80% or lower

3. Atmospheric pressure: 70kpa to 106kpa
