Medical Sterilizer

Model: - CVM-60S

Door type: Manual door, safety protectionMethod of Installation: - tabletop with a movable caster holding cart

Chamber type: Single chamberThe total chamber volume is 80 liters.Chamber volume that is usable: 60 liters.Chamber material: - Aluminum at the aircraft level

Shape of chamber: RectanglePower supply: 380V, 50Hz, three phases
Programs of four types: - Fast: 30 minutes; Standard: 38 minutes; Flexi Endo: 45 minutes; Vacuum Drying: 20 minutes

Humility detection is not a software function.Plasma stage power display; Pressure display; Time display; Temperature display
Input power: ≤3200WPower consumption at the content temperature is 1200 watts.Standby power: Approximately 25 wattsNoise: ≤60 dBOperation environment temperature: 5℃ to 40℃Operation environment humidity: 30% to 95% (no frosting)Atmospheric operation: 700 to 1060 hPaH2O2 dosage volume (ml): Fast: 3 mL per cycle; Standard: 6 mL per cycle; Flexi Endo: 6 mL per cycle

Cycle QNT/cassette: Fast: 12 cycles; Standard: 6 cycles; Flexi Endo: 6 cyclesChamber operating temperature: 45℃ to 60℃The maximum vacuum degree in the chamber is less than 80 Pa.Dimensions of the machine are as follows: 720mm x 860mm x 1100mm.Installation space: 1500mm x 1500mm x 2000mmInstrument shelf: - Type: mobile; Quantity and load capacity: 2; total 10KG; 5kg per shelf
Net weight: 245 kilogramsG.W. - 300 kg

Panel material: Q235 carbon steel with a plastic spraying painting.

Maintenance: six monthsGuarantee duration: Two yearsTouch screen: 10 inches; TFT true color; touch screen

Printer: Internal needle printerData recording and monitoring: Accessible at any time for review and printing.Internet of Things (IoT): port opening with HIS/CSSD/CME/CSD system, USB port, and RFID of endoscope sterilization tracking
