Medical Sterilizer

The economic burden of purchasing an incubator separately is alleviated by this unit, which serves as both an incubator and a dry-heat sterilizer. In each mode, the sterilizing and incubating mode offers five cycle programs for convenient operation. By implementing the precise PID control method, the system achieves both effective temperature control and power savings simultaneously.



The chamber temperature is nearly uniform due to the simultaneous heating of the four walls and the forced circulation of internal air by a fan. The external fresh air that is drawn into the chamber is already preheated, which minimizes the likelihood of a sudden temperature change.



The monitor displays the error code, an audible alarm is generated, and the executing cycle is automatically aborted for safety when an error occurs. Additionally, the monitor displays the actual temperature and remaining time of each process during operation.input:
output:Weight: 37 kilogramsAC 230V, 50/60Hz is the power source.

Power Consumption: 1,500 watts
Mode: Incubator/SterilizerMicroprocessor and PID controllers are examples of controls.Heat Transfer - Forced Convection Typeinput:
output:Environmental Conditions -* Up to 2,000 meters in altitude.* A temperature range of +5℃ to +30℃.

* A maximum relative humidity of 80%.* A fluctuation of ±10% of the nominal main supply voltage.* Installation Category (Overvoltage Category) Ⅱ, Pollution Degree 2.input:
output:Seven-segment, four-digit, LED display

Glass Door (Optional) - Triple Tempered Glass, 5 inches in thickness

Communication Port (Optional) - RS-232C Interface Communication Port

Printer (Optional) - Direct Thermal Printing Type, Paper Roll; W58 x Ø40 ㎜
