Medical Pendant

Arm Movement Range: 700-1100mm in radius.

Horizontal Rotation: 0-340° for independent or simultaneous rotation of the arm and terminal box.Instrument Platform: Two adjustable layers with an anti-collision design.

Gas Interfaces: 2 oxygen, 2 vacuum, 2 compressed air; secondary sealing, error-proof design. Electrical Outlets: 8 sockets, 220V.

Grounding Terminal: One equipotential terminal.

Infusion pump rack and adjustable stainless steel IV pole.Material: Electrostatically painted high-strength aluminum alloy.Customizable Options Are Available



The MGE-STP2D Surgical Pendant is a critical component of medical equipment in contemporary hospital operating rooms. It is primarily intended for the terminal transfer of medical gases, including oxygen, suction, compressed air, and nitrogen. This pendant provides significant benefits, including the ability to elevate the platform via motorized means, which guarantees both dependability and safety. The equipment's horizontal stability is guaranteed by its balanced design, which ensures secure and efficient operation. The pendant's long-lasting durability is guaranteed by its robust construction and surfaces that can be cleaned with standard disinfectants, which prevent contamination.input:
output:Product Specifications

High-Strength Aluminum Alloy Construction: Featuring a fully enclosed, corrosion-resistant design that is durable, easy to clean, and disinfect, the pendant's main body is constructed from a high-strength aluminum alloy, effectively preventing contamination.

Internal Wiring and Gas Pipeline: The tower body contains all power cables and gas pipelines, thereby preventing any relative movement between the equipment platform and the tower body.
