Medical Gas Manifold

The Weclearmed® ambulance oxygen manifold is appropriate for ambulances with a high oxygen consumption. This manifold is designed to feed bottled high-pressure oxygen into the main pipe of the control panel via a metal hose. The high pressure oxygen is transported to the oxygen terminal through the low pressure pipeline after being depressurized. This oxygen is utilized as a first aid source. The operating principle involves the decompression of high-pressure oxygen into low-pressure oxygen, which is then transported to the oxygen terminal via the appropriate pipeline.Product Descriptioninput:
output:The control panel of the Weclearmed® ambulance oxygen manifold is capable of connecting two or more oxygen cylinders simultaneously. To reduce the high-pressure oxygen to a low-pressure state. A centralized gas supply system is equipped with an ambulance manifold system.The control panel is composed of metal hoses that are connected to the oxygen cylinders via G5/8 threads. Each cylinder is connected to the control panel via a corresponding high-pressure switching valve, which independently regulates the corresponding high-pressure pipeline.The oxygen cylinders were connected at the end of the switching valve by high-pressure piping. The high-pressure gauge, regulator, and high-pressure pipeline are connected by the tee joint located at the center of the gas manifold.The oxygen pressure in the high pressure tubing of the control panel is monitored by the high pressure gauge.The regulator is employed to regulate the high pressure oxygen to the necessary pressure, which is then outputted to the low pressure end.The oxygen terminal, safety valve, and low-pressure gauge are all connected to the low-pressure end.
