Medical Facility Door Closer
| Applications | Medical Facility |
For single-leaf doors with a leaf width of up to 1100 mm, an overhead door closer with a guide rail is available.TS 3000 V overhead door closer with guide rail Installable on both the right and left sides of single-action doors, as well as fire and smoke protection doors.
Closing force that can be adjusted from EN1-4
Suitable for both right and left-handed doors without the need for conversion
The door is accelerated shortly before it is closed by the hydraulic latching action.
The speed of closing can be customized on an individual basis.Except for the closing force, all functions can be configured from the front.Application Areas
Doors that provide protection against fire and smoke
Single-action doors on the right and left.Single-action doors with a leaf width of up to 1100 mm
Installation of the door leaf and transom on the hinge and the opposite hinge side.Technical informationClosing force in accordance with EN 1154 EN 1 – 4
Barrier-free in accordance with DIN 18040, with a maximum leaf width of 1100 mm.
Leaf width (maximum): 1100 mmInstallation Type Installation of the door leaf on the hinge side, installation of the transom on the opposite hinge side, installation of the transom on the hinge side, and installation of the door leaf on the opposite
Maximum opening angle: 180°Fire protection doors’ suitability Certainly.Adjustable closing force Indeed, it is stepless.
Yes, the closing speed can be adjusted.Latching action is adjustable through a valve.No back check has been integrated.Adjustment of closing force position On the lateral side
Optional: Hold the device open.No. of integrated smoke switch
