Medical Facility Door Closer

Description of the ProductThe Briton 2400 Series is a compact concealed unit that is precision manufactured as a cam-action, slide channel door closer. The Briton 2400 Series provides a highly aesthetic solution that is fully concealed when the door is closed, as the closer body is mounted within the top of the door and the slide track is within the head frame. Additionally, it is highly resistant to abuse. Suitable for doors that are 44mm in thickness or greater.input:
output:The Briton 2400 Series bridges the gap between the requirements for fire and smoke control and the ease of operation required for accessibility by reducing the resistance encountered when opening the door, providing exceptional ease of use.Features

Minimal material removal from the door and frame is necessary for the compact extruded aluminum body.

High-performance cam action technology is highly efficient, ensuring a reliable closure that is effortless to open.

Needle roller bearings offer enhanced reliability and efficient operation by increasing the bearing load.

Power adjustment enables installers to modify the spring power to accommodate the door's size and location.

Springs made of silicon chrome alloy steel are designed to provide exceptional reliability and strength.

Reliable performance is guaranteed by hydraulic fluid of superior quality, which includes temperature compensation that eliminates the necessity for seasonal adjustments.

23mm wide aluminum slide track with nylon runner

Steel track arm with a powder coating

Note that the optional cushion stop is not a backcheck facility; it is intended to prevent doors from opening beyond the imit of the door closer.
