Medical Device Galvanic Isolator

A transformer that has been fully listed under the CAN/ES/IEC/EN 60601-1 standard provides continuous noise filtering, step-up and step-down capabilities, and line isolation to safeguard medical electronic equipment that is used in patient-care proximities.Safeguards sensitive equipment from surges and EMI/RFI line noise

Cumulative leakage current is less than 50 µA.

In the event of an overload, all outlets are automatically deactivated.

Provides complete isolation from the AC mains power input.Suitable for use in any industrial, network, or medical setting. Includes a two-year limited warranty.The IS300HGDV Isolator® Series Dual-Voltage 115/230V 300W 50/60Hz Medical-Grade™ Transformer, which has a full CAN/ES/IEC/EN 60601-1 listing, is ideal for safeguarding sensitive electronic equipment in patient-care vicinities. It has the ability to be configured for pass-through voltage operation, step-up voltage operation, or step-down voltage operation. The surge protection rating of 240 joules suppresses excess voltage to prevent it from damaging connected equipment, in addition to providing continuous EMI/RFI line noise filtering and line isolation.input:
output:An internal low-impedance isolation transformer component provides complete isolation from the input mains AC line. The cumulative leakage current of the IS300HGDV and connected equipment is reduced to less than 50 microamps by the Faraday shield, which also eliminates utility switching transients and harmonics generated by other on-site loads and mitigates the effects of utility-related surge conditions.input:
output:Transformer filtering offers continuous common-mode noise rejection without the need for wearable components. The IS300HGDV reduces 6000V IEEE 587 Category A and B ring wave and combination wave test surges to a mere 0.5V common mode.
