Medical Barcode Scanner

The MS-3 laser barcode scanner provides the most rapid read performance among compact embedded barcode scanners.input:
output:Decodes per second: up to 1000

Reading range: 51 to 254 millimeters

A broad scan angleEnclosure with an IP54 rating

Compact and Lightweight:The scanner, which measures 44.5 mm in square and 21.6 mm in height, is remarkably lightweight at 57 g, making it effortless to mount onto robotic equipment or into small spaces.input:
output:
High-Speed Scanning:
At a read range of 51 to 254 mm, Omron Microscan’s world-class decode algorithms and an adjustable scan speed from 300 to 1000 decodes per second guarantee precise readings, every time.input:
output:Wide Scan Angle:The wide scan angle of over 70 degrees and a factory customizable focal point contribute to space savings within your system, enabling greater flexibility with positioning.input:
output:Visual Indicators:The scanner’s performance is visually verified by illuminated LEDs located on its top.input:
output:Real-time Controls:The inputs consist of a trigger signal, a “new master” input, and a programmable input for the purpose of resetting counters or releasing outputs. A diverse array of conditions, such as diagnostic operations and matchcodes, can be programmed to activate the outputs.
