Medical Autoclave

The sterilizing effect is both rapid and dependable. The entire process of non-wrapped sterilization requires nine minutes, rendering it appropriate for emergency situations and the operation of multiple departments of equipment.

The sterilization chamber measures 38 cm by 18 cm by 7.8 cm, while the sterilization box measures 48 cm by 19.6 cm by 8 cm from the exterior.

The system is user-friendly, and the operation is indicated on the screen. Sterilization procedures can be safely terminated at any moment.

In the event of an issue during operation, the self-detection system will automatically cease operation and display the defective code on the screen.

It is appropriate for the sterilization of solid instruments and instruments with cavities, and it can be used for non-wrapped sterilization.



Simple to operate

The screen displays the system's operation. Sterilization procedures can be safely interrupted at any point.

Sterilization process real-time recordinput:
output:
The ultra-thin cassette box design facilitates faster heating and cooling.input:
output:
Minimum Operating Pressure: 242 kPa
Max. Input Power: 1.3 kVA

Operating Pressure Range: 42 kPa to 212 kPa br/>
Atmospheric Pressure Range: 70.0 kPa to 106.0 kPa

Ambient Temperature Range: +5°C to +40°CSteam Generator Power: 1.2 kVA ± 5%

Accuracy of the display: 0.1℃

Fuse - F8AL250V, 5 x 20 mmSafety Valve Setting Pressure: 0.25 MPa

Tank Capacity: 3.4 Liters

Water Vapor is the working medium of the equipment.Water - Deionized water, distilled water, purified water, laboratory water, and ultra-pure water.Working Relative Humidity: ≤85%

Normal Use Location: Workroom Power Supply Voltage: AC 220 V±22 VPower Frequency: 50 Hz ± 1 Hz
