Medical Air Compression System

• The exterior covering of the air compressor is finished with a high-temperature powder coating in a black color.

• A standard 220v 60hz electric motor is used in the belt-driven transmission, and other voltages must be specified in advance at the factory.

• The replacement and maintenance of components are effortless.input:
output:
Air-cooled aftercoolers:• The Main Air Refrigerated Aftercooler is constructed from carbon steel and features temperature aluminum heatsinks.

• The Secondary Air Refrigerated Aftercooler is a guardbelt mount type that is constructed with stainless steel and copper tubing and aluminum cooler heat sink fins. It includes a multiple connection block with relief, backflow, and automatic valves for each compression unit.



Aircraft:• ASME-specified air vessel with internal and external treatment (possibly incorporating a man-access hatch for maintenance and internal cleaning).

• The manufacturer's ASME stamp is required (ASME stamps are exclusively available for vessels lacking a man access hatch).input:
output:
Control Panel:• An electrical-electronic control panel is utilized to regulate the Régénération Air treatment system, as well as to coordinate alternation, simultaneous use, and stop.

• NEMA12 class enclosure with alarm detection and maintenance alert, as specified by NFPA99.

• A 7-inch touch screen display that allows for the control and monitoring of compressor operation status.input:
output:Regenerative tower air dryers:• The system includes regenerative tower dryers in duplicate, with normally open electric valves that are timed and controlled by the equipment control panel, and a drying temperature of -60°C.input:
output:Air filter system:• Moisture filters and 0.01 particle filters. The system includes carbon activated filters, optional antibacterial filters, and a final line pressure regulator in duplicate.
