Manual Polarimeter

Visual objective

Manual evaluationSimple to operateSpecifications

Measurement range: ±180°

The light source is a sodium lamp.Division Value - 1°Dial Venire Value in Reading - 0.05°

Magnification Ratio of the Magnifying Glass: 4X

Wavelength: 589 nm

Test Tube - 100mm/200mm
Weight in kilograms (kg): 5.8 kg

Instrument Dimensions (mm): 435*135*320

580*230*420 mm Packaging Dimensions (W*D*H)Polarimeter Accessoriesinput:
output:MicrotubeSuitable for automatic polarimeters, this sample has a loading capacity of less than 0.8 ml and a length of 50mm.input:
output:Thermostatic Tubeinput:
output:This section is dedicated to polarimeters that are equipped with a temperature control function.the sample loading is 2.5 ml for a length of approximately 100mm;And the non-corrosive type is available for purchase as an option.input:
output:Standard Quartz Tubeinput:
output:The sole calibration equipment for standard polarimeters and optical Brix, featuring user-friendly features, stable performance, and minimal environmental influence.input:
output:For customers to select from, the quartz tube reading comprises ±1°, ±5°, ±7°, ±34°, and ±68°.
