Product summary
• Distinct butterfly-shaped design.
• Capable of accurately evaluating all visual functions from all angles.
• at ease with the act of measuring.
• A comfortable feel, achieved through an exquisite manufacturing technique.
• All optic lenses are constructed with high-quality plated-film.input:
output:DescriptionSphere
Range: -19.00D to +16.75D Step: 0.25D; When used in conjunction with an auxiliary device lens + 0.12D Step: 0.12D
Cylinder
Range: 0 to 6.00D; when used in conjunction with an auxiliary cylinder lens, 0 to 8.00D. Step: 0.25D;
When used in conjunction with an auxiliary cylinder lens and a 0.12D step, the step is 0.12D.
Cylinder axis Step: 5°; Range: 0~180°
Rotary prism Step: 1; Range: 0 to 20
Cross-sectional Cylinder
The cylinder asis is synchronized with the cross cylinder lens.
PD modification Length: 50–75mm; Step: 1mm
Adjustable convergence
∞, 380mm (when PD 64mm)
Adjustable forehead ridge of 16mm. Vertex corned distance 13.75mm (from the corneal point to the standard lens surface)
Size
335(L)*320(W)*98(H)mm
5kg
• Capable of accurately evaluating all visual functions from all angles.
• at ease with the act of measuring.
• A comfortable feel, achieved through an exquisite manufacturing technique.
• All optic lenses are constructed with high-quality plated-film.input:
output:DescriptionSphere
Range: -19.00D to +16.75D Step: 0.25D; When used in conjunction with an auxiliary device lens + 0.12D Step: 0.12D
Cylinder
Range: 0 to 6.00D; when used in conjunction with an auxiliary cylinder lens, 0 to 8.00D. Step: 0.25D;
When used in conjunction with an auxiliary cylinder lens and a 0.12D step, the step is 0.12D.
Cylinder axis Step: 5°; Range: 0~180°
Rotary prism Step: 1; Range: 0 to 20
Cross-sectional Cylinder
The cylinder asis is synchronized with the cross cylinder lens.
PD modification Length: 50–75mm; Step: 1mm
Adjustable convergence
∞, 380mm (when PD 64mm)
Adjustable forehead ridge of 16mm. Vertex corned distance 13.75mm (from the corneal point to the standard lens surface)
Size
335(L)*320(W)*98(H)mm
5kg
