Manual Distillation System

INCLUDING A HEATING AND COOLING SYSTEM.APPLICATIONS

Separation of cannabinoids.

Chemical compounds that are susceptible to heat undergo thermal separation. Purification of synthetic organic materials.

A biological extraction solution that effectively separates components. Industrial waste recycling.

The removal of toxic substances from the food industry. The removal of an unusual odor and the decolorization of organic compounds. FEATURES

Low operating pressures

A brief period of residence.High rates of evaporation.

Under the incrustation in the evaporator's wall.
A magnetic sealed bearing that is devoid of grease, valves, and joints. Ideal for materials that are susceptible to heat.

Operating temperature: up to 200/300ºC.

Operating temperature: -30 ºC.220V / 50-60Hz is the electrical requirement.Engine power: 120 watts. STANDARD EQUIPMENT

1. Jacketed feeding flask with a manual feed valve.2. Magnetic drive for the stirrer.3. Internal condenser with glass tank.

4. Dry and cold ice siphon.

5. Circulator for heating jacketed feed containers.

6. Circulator for heating coated glass tanks.(-30ºC)

7. Circulator for internal condenser heating and cooling (< 5 p.a.)

8. Vacuum pump.

9. Control system.10. Reception flasks (residual and distilled).
