Mammography X-Ray Film Printer

The KND6320 dry laser imager is a thermal imaging printer that is intended to replicate image data that is transmitted over the network in DICOM format. input:
output:CT (computed tomography), MRI (magnetic resonance imaging), digital X-ray imaging, fluoroscopy, image archiving and communication systems, ultrasound, nuclear medicine, portable X-ray imaging, mammography, dentistry, and other imaging application requirements are all connected and matched by the DICOM protocol. The direct thermal technique of dry laser imagers can generate exceptional grayscale prints with diagnostic quality using imaging media.Product Parameterinput:
output:
508 dpi (20 pixel/mm) geometrical

Film throughput: 70 sheets per hour (14 x 17); 90 sheets per hour (8 x 10).14-bit resolution

Film supply tray Two supply trays, each containing 100 sheets

Film Size: 8 x 10 inches, 10 x 12 inches, 11 x 14 inches, and 14 x 17 inches Film Type: Medical Thermal Film

Cassette for film input The entire film is prepackaged in a factory-sealed input cassette.10/100 Base-T Ethernet port (RJ-45)

DICOM 3.0 InterfaceImage quality Utilize the automatic calibration feature of the integrated densitometer.Image Control Contrast/Grayscale/Polar/Rotate/Saturation/Scale

Control Panel Light background LCD display, online, alarm, fault, and state

Keyboard switch Menu navigation button and power supplyIntel processor220V±22V AC/50Hz/600W power requirementsWeight: 45 kilograms

Work Temperature: 0℃ to 35℃Work temperature: 35℃ to 90℃ Storage temperature: -22℃ to 50℃ Storage humidity: 30% to 95%machine's foundation Optional
