Maldi-Tof Bacterial Identification System

Autobio developed the AutoMimo system to enhance the efficiency of pipetting and streamline the lab workflow when conducting experiments with the MALDI TOF Microbial Identification System. The instrument is also compatible with MALDI TOF from other brands.
Featuresinput:
output:
A standardized and high-precision pipetting system with a new gas-path mode, ensuring that the 1μL pipetting CV is no greater than 1.4%.



1000 wells per hour, continuous pipetting, multiple pipetting modes.input:
output:
The high-efficiency air purification system and timed ultraviolet sterilization module effectively reduce biological risks by preventing bio- and chemical hazards in the operator and laboratory environment.



Utilize an automatic alarm system in conjunction with a real-time operating status display module to dynamically monitor the instrument's abnormal status.input:
output:Software interface that is both user-friendly and straightforward, capable of accommodating a wide range of needs.input:
output:The reagent vial should be loaded without any additional dispensing.input:
output:The operator's physical safety is safeguarded by ergonomic engineering.input:
output:The Incubation system is highly efficient, allowing for the precise control of heating and the rapid preparation of samples.input:
output:Specificationparameter



Dimensions (L'W'H): 588 mm x 562 mm x 510 mmWeight: 58 ± 2 kg Performance:The sample volume ranges from 1 pL to 200 pL.1 pL Pipetting repeatability: CV<1.4%input:
output:200 pL pipetting repeatability: CV<0.4%input:
output:Installation Requirementsinput:
output:Relative humidity is less than 70%.input:
output:Temperature range: 10°C to 30°CStable, horizontal, four-point placement that can prevent vibrations
