Magnetic Therapy Unit

The square wave electric current generator embedded in the unit has a pulse duration that is adjustable and a frequency that ranges from 2 Hz to 100 Hz.

By modulating the implementation time of the circuit that supplies current to the applicators, the intensity of the impulsive magnetic field is adjusted to range from 10 to 100 Gauss.input:
output:Biomedical operates in two modes:

1) Manual

2) Protocols that are predetermined

The keypad's ability to memorize treatments enables the storage of up to five programs (free or preset), which can be quickly retrieved by utilizing the associated keys.input:
output:Specifications:

- Six languages that can be selected

- Power supply: 230V/50-60Hz

- Maximum absorbed power: 22 volts

- Inner fuses of the T500mA (delayed) type, 5x20

- The output frequency ranges from 2 to 100 Hz.

- Maximum intensity: 100 gauss (10 mT)

- Night Program Frequency: 1000 to 5000 Hz (step 500)

- II BF electrical safety class (IEC 60601-1)

- Medical Device Class IIa (MDD 93/42/EC)- Device IP20 level of protection - Applicators IP20 level of protectionAccompanied by:- One 2-meter power supply cable- Two transducers/applicators- One 8x60 cm Velcro elastic band- One 8x100 cm Velcro Elastic Band- One ABS case
