Led Examination Light

The Avante Vista is a compact LED examination light that emits a powerful light and features two-stage dimming. The Avante Vista LED's smooth arm articulation facilitates the control of its positioning.input:
output:The light produces minimal radiant heat, ensuring that clinicians remain comfortable and cool throughout extended surgical procedures. The Avante Vista LED is a highly efficient device that generates uncompromising illumination while demonstrating economical energy consumption.



Contact an Avante representative today to obtain additional information regarding the Avante Vista LED Examination light.input:
output:Characteristicsinput:
output:A powerful illumination is provided by a compact, affordable light.input:
output:
The LED array provides the highest level of color accuracy and sharpness.input:
output:
Two-stage dimming enables the regulation of brightness within the illumination field.input:
output:Smooth arm articulation is accompanied by a compact head design.input:
output:The maximum output is 50,000 Lux.input:
output:Bright white illumination at 4,300°K.input:
output:Color Rendering Index: 97.input:
output:LEDs with a lifespan of 50,000 hours.input:
output:Radiated heat is virtually nonexistent from the light array.SPECIFICATIONSinput:
output:Optical Parametersinput:
output:Number of LEDs: 8input:
output:Output: 55,000 Lux at a distance of 24 inches (0.6 meters)input:
output:CCT: 4,300° Kinput:
output:CRI: 97input:
output:Focal length: 24 inches (0.6 meters)input:
output:Levels of dimming: Twoinput:
output:Dimming percentages: 50% and 100%input:
output:Endo mode is not applicable.input:
output:Light field (d10): approximately 6.0 inches (152 mm) in diameterinput:
output:Light field (d50): approximately Ø3.5 inches (Ø89 mm)input:
output:Radiance: 71 watts per square meterinput:
output:Electrical SpecificationsSupply circuit: 100-240 VAC, 50/60Hzinput:
output:Fuse rating: 1.5 amps/250 voltsinput:
output:The power consumption of the light head is 16W at 24VDC.input:
output:Mechanical Specificationsinput:
output:Head weight: 5.6 lbs (2.5 kg)input:
output:Light head dimensions: Ø9.2 in (234 mm) | 2.6 in (66 mm)input:
output:Weight of arm assembly (single): 48.3 lbs (22.0 kg)input:
output:Arm assembly weight (dual): 77.1 lbs (35.0 kg)
