Laser Diffraction Particle Size Analyzer

The Bettersizer S3 Plus is a single instrument that integrates dynamic image analysis and laser diffraction. It is capable of determining the size and shape of particles ranging from 0.01 μm to 3500 μm. It is the most potent size and shape analyzer for enthusiastic researchers who conduct top-tier scientific research due to its unparalleled resolution and exceptional sensitivity for either ultrafine or oversized particles.● The laser system has a measuring range of 0.01 - 3,500 μm, while the image system has a range of 2 - 3,500 μm.● Simultaneously obtaining size and shape results by integrating laser diffraction and dynamic image analysis in a single instrument.● The measurement of ultrafine particles as small as 0.01 um is made possible by the patented DLOI (Dual Lenses & Oblique Incidence) system.
● The dual-camera imaging technology is capable of detecting oversized particles up to 3500 um and displaying particle images in real time.
● The refractive index of unknown samples is determined through refractive index measurement, which enhances the reliability of the results.● Adherence to ISO 13320, USP, CE, and 21 CFR Part 11

1. Overview of the Bettersizer S3 Plus Particle Size and Shape AnalyzerThe Bettersizer S3 Plus is a laser diffraction particle size and shape analyzer that is equipped with two high-speed CCD cameras (0.5X and 10X magnification) to capture images of the sample being measured. The particles that are dispersed in the medium of choice are pumped through two sample cells during the measurement. In the initial instance, particles are illuminated and scattered by short-wave laser light (532 nm). In an angle range of 0.02° to 165°, the 96 detectors detect optical signals.
