Laboratory Vacuum Pump

The VACSTAR dry 4-chamber membrane vacuum pump is a low-maintenance, chemical-resistant, and powerful device that facilitates separation, filtration, and removal. The VACSTAR control system is the optimal choice due to its integrated vacuum controller and removable display. The controller provides a mode that is appropriate for the desired process, ranging from automatic to manual operation, as well as pumping or an evacuation and cleaning function.



High-performance suction

The suction performance of VACSTAR is exceptional, with a minimum of 2 mbar and a flow rate of 22 l/min.input:
output:
Vacuum controller with removable WiCo that is integrated

The operating mode can be easily selected by either the intuitive operator menu or a remote control, depending on the application.input:
output:Safeguards the environment and the user

A downstream vacuum safety emission condenser (VSE1) is a component of the VACSTAR system. This consistently safeguards the environment and laboratory employees from hazardous exhaust gases.input:
output:Data TechnicalThe maximum pump rate (50/60Hz) is 1.32 m³/h.Maximum pump rate (50/60Hz): 22 liters per minute

Final pressure in the absence of gas ballast: 2 mbar

Four suction levels are available.Cylinder: Four

Suction side connection diameter: 8 mmPressure side connection diameter: 8 mmInput pressure: 2 to 1030 mbarYes, the boiling point can be detected.Solvent library: YesVacuum control with analog speed: YesSpeed control: Rotating a knobSpeed range: 285 to 1200 revolutions per minuteTFT display

Pressure units and scales include mbar, hPa, mmHg, and Torr.

Vacuum sensor: YesCeramic Al2O3 vacuum sensor type

Maximum pressure for the pressure sensor is 1.2 bar.

Absolute measurement range: 1 to 1030 mbarControl range: 1 to 1030 mbarResolution pressure: 1 mbarUncertainty of measurement: 1 mbarVentilation valve: YesCondensate trap: YesYes, an emission condenser is present.Timer: Yes
