Laboratory Vacuum Pump

For applications that are oil-free and dry

A long service life and a slim, compact design Simple maintenance and straightforward servicing

A diaphragm pump that is highly resistant to chemicals is constructed with PTFE or PTFE compounds for all parts that come into contact with gas.input:
output:Data TechnicalPump rate maximum (50/60Hz): 1.7 m³/hThe maximum pump rate is 28.3 liters per minute at 50/60 Hz.The final pressure is 7 mbar in the absence of a gas ballast.The final pressure with a gas ballast is 15 mbar.Levels of suction2Cylinder 2Suction side connection diameter: 10 mmGas ballast valve: Yes Connection diameter pressure side: 10 mmInput pressure: 7 to 1050 mbar1380 - 1680 rpm speed rangeNominal speed: 1380 revolutions per minuteLow-pressure noise65 decibels (A)Dimensions (W x H x D): 245 x 155 x 320 mmWeight: 11.5 kilogramsAmbient temperature that is permissible10 to 40 degrees CelsiusThe permissible relative humidity is 80%.

Protection class in accordance with DIN EN 60529IP 54Voltage: 230, 115, and 100 volts.Frequency: 50/60 Hz180 watts of power input
