Laboratory Thermostat

The ICC basic compact immersion circulator is designed to temper liquids at temperatures of up to 150°C. Appropriate for use in bath vessels that are either open or covered. The ICC can be utilized for both internal and external applications due to the integrated pressure/suction pump. Connect the optional pump set. The ICC also offers an optional cooling coil that enables it to operate at temperatures that are close to ambient. The program function has the capacity to save and execute up to 10 individual procedures with 10 steps. The ICC circulator is the first of its kind in its category, featuring a clever stand that enables safe storage and comfortable transport, as well as an integrated carrying handle.input:
output:
The intuitive control of all process parameters is provided by the large, color TFT screen (control version).input:
output:• Temperature stability: ± 0.02 K

• A powerful, speed-controlled pressure/suction pump

• A holding clamp is included to secure the circulator to a bath.• Integrated brackets and a convenient carrying handle

• A large, easily readable LED display that indicates the temperature and speed of the pump

• Intuitive menu navigation is achieved through the use of push and turn buttons.• Safety circuit that can be adjusted• Visual and acoustic safety warnings• A USB/RS232 interface is available for PC control and documentation via labworldsoft®, as well as for online firmware updates.Classification in accordance with DIN 12876: III Appliance type: Compact immersion circulators

Identification in accordance with DIN 12876: FL

2000 watts of heat are produced.

Temperature display: YesTemperature regulation: PT 100

Temperature sensor: PT 100

PT1000 safety temperature sensorWorking/Safety Temperature Display: LED
