Laboratory Reactor

The DrySyn Snowstorm reactor provides an appealing solution to the chemistry of low-temperature reactions.input:
output:The formation of ice around the reactors at sub-ambient temperatures is prevented by purging the dome with nitrogen or argon.input:
output:The unattended operation of up to 27 vials at any given time is enabled by active temperature control, which ranges from +150 oC to -30 oC.

The DrySyn Snowstorm provides a compact benchtop footprint, which enables it to increase throughput and screening without occupying valuable fume hood space.input:
output:The DrySyn SnowStorm reactor is depicted in our gallery images in conjunction with both Grant and Julabo chillers.input:
output:Specification

The maximum temperature of the solution is -30°C.

The kit includes a cooling base, a glass dome, and three standard reaction vial inserts, as specified below.

This base is also compatible with our Multi/Multi-M/Multi-S range of inserts for round bottom flasks ranging from 5 mL to 500 mL.

Scale for Vial/Tube Reactions:

Standard sizes, with the exception of the 27.40mm and 28.20mm options, are each four positions:input:
output:
11.80mm (accommodates 2 mL HPLC sample vials)15.00mm (accommodates 1 dram vials)16.20mm (suitable for CEM microwave tubes)17.40mm (suitable for Biotage 2-5 mL microwave tubes)

20.20mm (suitable for robot tubes)24.40mm (compatible with Radleys tubes)25.75mm (suitable for Wheaton reactor vials)27.40mm (accommodates 20 mL Scintillation vials) This size is a three-position size.

28.20mm (suitable for Biotage tubes of a substantial size) this size is three positions

Individualized: Select a diameter that is not greater than 28.20mm.Composition: aluminum that has been anodized

The diameter of the base is 87mm.
