Laboratory Reactor

The reactor system for organic or aqueous syntheses is EasySyn. It guarantees the safety and reproducibility of chemical reactions as they transition from the laboratory to the pilot scale.input:
output:The EasySyn 5000 Advanced package is a comprehensive reactor system designed for laboratory use. It is also possible to automate all processes by utilizing the IKA lab software labworldsoft® 6. The materials utilized are of exceptional quality, enabling operation at temperatures ranging from -50 to 200 °C and a negative pressure of up to 3 mbar.input:
output:
The LT 5.40 draining set is included in EasySyn Advanced. The reactor vessel can be easily replaced and the tempering fluid can be drained from the double jacket in a fast and clean manner using the special valves.input:
output:
Additionally, EasySyn 5000 Advanced comprises the following:

• Stand system that is ergonomically designed

• DN 150 vessel clamp for reactor vessel support• A 5000 ml reaction vessel with a bottom discharge valve, constructed from chemically resistant borosilicate 3.3 glass, is double-walled.The drain valve's spring-loaded valve spindle is designed to prevent glass breakage.

• Reactor lid with a variety of openings (1 x NS 29/32 center glass joint, 2 x NS 29/32, 1 x NS 14/23) to facilitate flexible adaptation to the desired application

• DN 150 FEP-coated O-ring and DN 150 clamp ring to guarantee chemical resistancePowerful overhead stirrer EUROSTAR 100 control with 100 Ncm, featuring a keyless chuck for effortless and rapid mounting of the stirring tool.• Propeller stirrer coated with PTFE for excellent chemical resistance and mixing• For vacuum operation at a pressure of up to 3 mbar, a high-quality stirrer guide is available.Drainage set LT 5.40 with temperature control hoses and valvesAvailable in vessel sizes that accommodate volumes of 500, 1000, 2000, and 5000 ml.
