Laboratory Ph Meter

• Auto-buffer recognition with 1 to 3 points of calibration• A pH buffer set that can be selected, which includes the USA and NIST options

• Accurate readings across the entire range are guaranteed by automatic temperature compensation

• The user is assisted in determining whether to replace the sensor by the automatic electrode diagnosis.• The setup menu enables the configuration of the number of calibration points, alarm limits, hysteresis value, and 4 to 20 mA output.• The reset function automatically restores all settings to their original factory settings.input:
output:
pH -pH range: -1.00 to 15.00Resolution: 0.01 pHPrecision - ±0.01 pHCalibration Points: 1 to 3 points

pH buffer options include the following: USA (4.01/7.00/10.01) and NIST (4.01/6.86/9.18).mV -Range: ±1000 mVResolution: 1 mVPrecision - ±1 mVinput:
output:Temperature:

Precision - ±1°C/±1.8°F Range - 0~100°C/32~212°F Resolution - 0.1°C/0.1°F Offset Calibration - 1 point, reading ±10°CCommunication -Signal Output: 4-20 mALoad - Maximum 500 ΩAlarm settings include low and high alarms, with a pH range of 0.00 to 14.00.

RS485 Communication Interface

Connection Terminals - Detachable screw terminals Other Specifications -Temperature Compensation: automatic, ranging from 0°C to 100°C

Ambient temperature must be less than 60°C, and the relative humidity must be less than 80%.Power Requirements: DC24VDimensions: 96mm in length, 96mm in width, and 75mm in height.Weight: 350 grams
