Laboratory Ph Meter

Microprocessor-based pH meter Model 1015 is a solid-state instrument that is intended to deliver accurate pH and mV measurements. The instrument is designed to provide improved accuracy and reproducibility by utilizing the most recent microprocessor technology and advanced engineering techniques. The system is equipped with user-friendly prompts that provide guidance throughout the measurement process.input:
output:The system is equipped with eight soft touch membrane keys that facilitate operation. It is capable of performing calibrations at a maximum of five points. It is equipped with the capacity to store 1000 samples, which are stored in the memory even when the system is turned off. The system also includes the ability to connect a thermal printer or dot matrix printer via serial RS232, allowing for the printing of any of the stored results.input:
output:The instrument is highly beneficial for a variety of applications, including agriculture and soil analysis laboratories, swimming pools, water quality control in boiler feed water, water works departments, fertilizer plants, petroleum refineries, breweries, and water purification plants.Features: – Measures pH, mV, and temperature5 point calibration 128 x 64 dot graphical LCD displayAuto Buffer Recognition FacilityA maximum of 1,000 samples may be stored.

Serial Dot Matrix/Thermal Printer Attachment Specificationsinput:
output:pH range: -2.000 to 20.000input:
output:pH – Selectable – 0.1, 0.01, 0.001input:
output:Accuracy – pH ± 1 digit, ± 0.002input:
output:Graphical LCD Display with a Resolution of 128 x 64 Dots for Readoutinput:
output:Calibration – Automatic and Manual with 5-point Calibrationinput:
output:Auto Buffer Recognition – pH or User Selectable – 1.680, 4.000, 7.000, 9.200, and 12.450input:
output:Relative Stability – ± 0.002 pH/Hourinput:
output:Temperature Compensation – Automatic/Manual, 0 to 100°Cinput:
output:millivolts -Range: 0 to ± 1999.9 mVinput:
output:Resolution: 0.1 mVinput:
output:Precision – ± 0.1 mV, ± 1 digit
