Laboratory Granulator

For your laboratory-scale and research-and-development fluid bed processing needs, the XENA-V FBS is the optimal solution.

The compact design enhances work efficiency and minimizes installation complications.

Compatible with nearly all fluid bed processes, including Granulating, Drying, and Coating.

The system operates automatically and does not necessitate the presence of a constant operator.

Economical, user-friendly, and optimized for optimal processing efficiency.

A touchscreen that is user-friendly and features schematics that are easy to read for control and diagnostics, enabling the operator to monitor all aspects of the cycle.

The software is entirely compliant with 21CFR part 11.



Technical Information



Container Volume [ℓ]: 6

Drying capacity is 2.5 kg, granulating capacity is 2.2 kg, and coating capacity is 1.5 kg.*Specific Gravity: 0.6

Container Diameter [mm]: Ø220

Filter Housing: Four filters (5 micron) and pulse blowback

Spraying Process: Top and Bottom Spray System (Tilting and Swiveling)
Bore diameter (mm) of liquid insert: 0.7

Container home position sensor

Room lamp/inspection lightFan Power* [kW]: 2.55 60Hz

Fan air volume [CMM]: 6Fan Differential Pressure [mmAq]: 2,200Heater Capacity [kW]: 3.5Temperature Range [: Room Temperature ~90]

Watson-Marlow Peristaltic Solution Pump

Filter: Cartridge, HEPA [OUTLET] / Pre, Medium, HEPA [INLET]

Compressed air pressure is 5 bar.

Power Supply: 7.5KVA, AC220V(3Ph), 50/60Hz

Dimensions in millimeters: 1050 [W] x 980 [D] x 1750 [H]

*Control Part br/>


*Weight* [Kg]: 450

*Including Container // Approx.12.1" Touch Screen

All controls are located on a single screen

User Login (Multi Recipe Function)Real-time Monitoring (Differential Pressure, Temperature, and Fan Air Velocity)Data graph display and storage (DAQ Program-Data Acquisition)
