Laboratory Freeze Dryer

The VaCo series is a freeze dryer and lyophilizer that is designed for entry-level use. The laboratory freeze dryer is optimally suited for a diverse array of laboratory tasks due to its modular design. The housing is constructed from durable stainless steel. The basic unit can be complemented by a variety of modules, contingent upon the specific application. The units are constructed in accordance with the new EU F-Gases Regulation (EU) No. 517/2014 and are optionally available with a -50 °C condenser or -80 °C condenser. Natural refrigerants that are environmentally friendly are implemented.



The subsequent alternatives are accessible:



The acrylic glass chamber is available in a variety of dimensions, which are contingent upon the unit's size. The connecting piece to the ice condenser is represented by the base plate. Vacuum connections (NS 29/32) are also available for the chamber lid upon request.



Stainless steel chamber: It is advisable to employ a stainless steel chamber when employing organic solvents or substances that harm acrylic glass.


The aluminum insert rack is available in two packages. With shelves that are either heated or unheated. The process is expedited by the heated shelves.


Trays for drying: In order to complement the shelves, stainless steel drying trays are accessible.Drying rake - stainless steel, with a three-way valve (NS 29/32): If drying is to be conducted exclusively in glass flasks or ampoules, the drying rake is the optimal choice. Furthermore, an ampoule adapter is accessible to extend the vacuum valve to accommodate 16 ampoules.input:
output:Device for sealing: It is frequently necessary to vacuum seal lyophilizates in vials after they have been dried. From the VaCo 5, this alternative is feasible.
