Laboratory Conductivity Meter

There are two operational modes: CTA and CTM.input:
output:Function for recording measurementsinput:
output:Mobile device data acquisitioninput:
output:PresentationThis conductimeter is one of the products in the Initio 2 range that enables the measurement of ionic conductivity in a solution. This versatile measuring instrument is well-suited for the instruction of Physics and Chemistry in high school. It can be employed in a variety of ways: – As a standalone measuring device, the Initio 2 can be used to: * read measurements on the device screen and save them for analysis on a computer – read measurements directly from a tablet using the Wifi module – connect up to five mobile devices to the same Initio® 2 – connect to an ExAO consoleinput:
output:Specificationsinput:
output:Details: – Conductivity: 2 mS.cm-1 and 20 mS.cm-1.

Range of measurement:0.001 mS.cm-1 resolution, accuracy ± 1% of full scale, and a range of 0 to 2 mS.cm-1

Resolution of 0.01 mS.cm-1, accuracy of ± 1 % of full scale, and a range of 0 to 20 mS.cm-1.

Operating mode (probes must be ordered separately):

– CTA: compatible with CTA probe (ref. 701330) on mini DIN connector.

– CTM: compatible with banana plugs and the CTM probe (ref. 701329).

Temperature range: 0°C to 50°C

The optimal temperature range for compensation is 15°C to 35°C.input:
output:Includes a micro USB cable and a power adapter for battery charging.

Display: 128 x 64 backlit graphic screen.

Analog outputs:* -5 V to +5 V on 4 mm safety banana sockets.

* A 3.5 mm jack with a voltage range of 0 to +5 V.

Dimensions: 95 x 123 x 44 mm.
