Laboratory Colorimeter

Controlled by a microprocessor.Automatic zero absorbance and 100% transmittance.Alphanumeric 20-character, two-line liquid crystal display.APPLICATIONSQuality control, environmental control, and chemistry laboratory. FEATURES

Special filters with a 30 nm band pass are employed to achieve a wavelength range of 400 to 800 nm.
12 positions for filter disc wheel selection.
420, 440, 490, 520, 550, 580, 620, and 680 nm are the standard filters.

Expanded absorption range: -0.3 to 3.5 O.D. in real time.
Transmission: from 0 to 100% T.Photometric accuracy: greater than 1%.Photometric precision: ±1%.Photometric stability: 0.004 A/hr.Light source: Tungsten lamp with an extended lifespan.Solid-state detector.

10 mm cuvettes or test tubes with a diameter of 12 and 16 mm are used as the sample chamber.

A minimum volume of 1 ml is required.

Display: Two lines of twenty characters on an alphanumeric LCD display.Transmission T % is the calculation function.Absorbance, concentration by factor, or standard concentrations.

Software calibration: Self-adjusting.

The results can be downloaded to a computer via a USB interface.CONTROL PANELON/OFF switch.

LCD display that is interactive.

Function and numeric keypad.
