Jaundice Meter

BY-D-I Jaundice Meter utilizes state-of-the-art fiber, optical, electronics, and information processing technologies to dynamically monitor the percutaneous value of neonatal serum bilirubin. The light and electricity are organically combined to achieve this. The device is capable of rapidly determining the percutaneous bilirubin value in relation to the serum bilirubin concentration through the neonatal skin, thereby eliminating the pain that is caused by repeated blood samples for neonates and reducing the challenges faced by medical personnel in collecting blood samples. In addition, the device is noninvasive.input:
output:Technical Parameters:
Method of Measuring Light ReflectionXenon flash light sourceLCD display br/>
Range of Measurement: 0.0 to 29.9 mg/dL (0.0 to 425 μmol/L)Error in Indication

00~15±1(mg/dl); 16~25±1.5(mg/dl)

Accuracy Measurement RSD: 2%

Battery: Four triple A rechargeable nickel-metal hydride batteriesAfter each full charge, the time is measured 800 times.Units of Measurement: mg/dL; μmol/LAverages are determined by measuring two to five sets.

Calibration Plate

A white screen indicates a concentration of 00.0 or 00.1 mg/dl, while a yellow screen indicates a concentration of 20.0 ± 1 mg/dl.Operating Temperature: 10 to 30 degrees CelsiusWorking relative humidity must not exceed 80%.

Operating Atmospheric Pressure: 75 Kpa to 106 KpaPower SupplyInput: AC220V 50Hz;DC6.0V 0.5A output

External Dimensions (W*D*H): 175*68*26mmPackage Dimensions (W*D*H): 275*135*235 (carton box)Net Weight (kg)

0.157 (including batteries)

0.11 (without battery)

Gross Weight (kg): 1.33
