Irrigation + Suction Fluid Management System

The four fields of application (Gynecology, Laparoscopy, Urology, and Arthroscopy) in a single unit.

In the proven wash mode, the system is equipped with high pressure and fluid capacity, which allows for more flexibility in application and faster and improved visibility. Rapid response times in the event of pressure fluctuations. In the event that intra-articular pressure is elevated, pressure reduction is automated and implemented promptly. The pump can be positioned below the patient's level to compensate for the height difference. The display will then automatically display the actual intra-articular pressure.



• AUTOMATIC SELF-TESTING OF POWER AT 100mmHg, 200mmHg, 300mmHg, and 400mmHg.

• The Piezo Pressure Sensor that is the best in its class.
• Priming control that is dedicated.
• Control of fluid flow rate.
• Pressure control that is both more precise and rapid.• Disposable tubings that are free of EHP.• Sterilized tubing that is non-disposable.• Visual and acoustic notifications in the event of improper tubing placement• The channels for irrigation and suction are autonomous.• The irrigation system is based on the peristaltic pump module.• The high-quality vacuum pump module is responsible for the suction.• Predefined suction and irrigation parameters • Compatibility with a variety of laparoscopic suction-irrigation instrument models • Technical Specifications

Flow rate: 0.01 to 1.0 liters per minute.Pressure ranges from 50 to 400 mmHg.Suction: 0.65 bar

Control:... Screen that is touched

• Adheres to the medical EMC standard• Class 1 Equipment• Ordinary Water Ingress Protection, IPX0Equipment Dimensions: 310 mm x 120 mm x 330 mm.Weight: 7 kilograms

Electrical: Primary: 50/60 Hz, 100-240 VAC,Fuses: Two, Power Rating: 150 VA

Environment: -

Operating Temperature: 5°C to 40°CRelative humidity ranges from 30% to 95%.

Storage and Transportation: - 10%, 20°C to 60°C
