Intel® Core I7 Medical Box Pc

UL/EN 60601-1-2 Certified Medical Grade 4thIntel® 12th Gen. (Alder Lake S) Core™ Processor with W680 chipset.4 x 288-pin ECC/non-ECC Long-DIMM DDR4 3200 MHz, with a maximum capacity of 128GB (32GB per DIMM).

2 x M.2 M.Key PCIex4 Gen 4 SSD (Support NVMe SSD), 1 x SATA3 SSD1 x PCIex16 (Gen4), 1 x PCIex8 (Gen4), 1 x PCIex4 (Gen4)Three display outputs are available: HDMI, DP, and VGA. 1 x USB Type C, 5 x USB 3.2 Gen2, 1 x USB 3.2 Gen1, 2 x COM, 3 x LAN (2.5Gb)

TPM 2.0 On Board



Mechanical and Environmental



Cooling Smart Fan, Noise less than 30dB at 25℃ (ambient temp.)

Power Input / Consumption - ATX PWR (24+8-pin)

Power Adapter AC input 100~240V / 47 ~ 63 Hz / 900W

Operating Temperature Temperature: 0~40℃ (0~50℃ by project) / Storage Temperature: -20~60℃ Humidity: 20~90%, non-condensing Housing SECC with hospital white painting

Dimensions (Net): 319 x 158 x 436 mmCertification

Weights (Net) - TBD kgCE: EN 60601-1-2 (V4.1), EN 60601-1 (V3.2, by project)VCCI: 2016-11, Class B (PSU with PSE -TBD)FCC: Class B, Part 18UL: ANSI/AAMI ES60601-1:2012 (V3.2) by projectcUL: CAN/CSA-C22.2 No. 60601-1:2014 (V3.2) by project ISO 14971 by project Options1. Wi-Fi is available 24/7.2. 2.5-inch solid-state drive module3. Windows 10 IoT Enterprise4. Windows 11 IoT GAC (64-bit)5. 7-inch LCD with a resolution of 800x480 pixels6. 7-inch touch-screen PCAP7. Terminal pin with equipotential
